Brunel SP300 Phase Contrast

Brunel SP300 Phase Contrast

The Brunel SP300 trinocular microscope complies with the test slide reading required by the Health and Safety Executive for asbestos fibre counting which makes it exceptional in the world of phase contrast. These are robust industrial microscopes finished to a very high standard and with a very modern design. The light source is a Kohler LED unit integral to the base of the microscope. This makes the microscope an ideal instrument for phase contrast applications, and the trinocular SP300 is, we believe, the lowest priced phase contrast microscope that meets the HSE specification for asbestos fibre counting that is currently available and these specifications are exacting. We are confident therefore that whatever your phase contrast requirements are - particularly for diatom identification - this is the microscope that delivers.

A particular feature is the large rectangular mechanical stage with drop down co-axial controls. The SP300 is specifically configured to provide the optical specifications needed for phase contrast. This consists of infinity corrected x4 bright field and x10, x20, x40 and x100 (oil immersion) plan brightfield phase contrast objectives together with an easy to operate Zernicke phase contrast condenser with matching phase rings. The extra wide field x10 eyepieces are excellent and have integral fitted eyecups. The co-axial coarse and fine focus controls have a graduation reading in 2 microns for an estimate of depth measurement. The total focus range covers 35mm and the movement runs in extra wide precision ball-bearing hardened steel tracks. Tension adjustment and safety auto focus stop units are fitted as standard.

Price: 2,141.67 (Excluding VAT at 20%)
